The Art of Analog Layout, 3rd edition

  • Alan Hastings

$9.99per month

6 monthly payments or pay $59.94 one-time

eTextbook

ISBN-13: 9780138059071 (2023 update)

Purchasing Instructions

This form contains two groups of radio buttons, one for Exam Pack purchasing options, and one for standard purchasing options. Only one option can be chosen for purchase. Any option that is selected will deselect any previously selected purchase option.

eTextbook + Study Prep

ISBN-13: 9780138059071 (2023 update)

  • Find it fast

    Quickly navigate your eTextbook with search

  • Stay organized

    Access all your eTextbooks in one place

  • Easily continue access

    Keep learning with auto-renew

The Art of Analog Layout covers the issues involved in successfully laying out analog integrated circuits. It  provides clear guidance and presents the material in an easy-to-understand way, without compromising detail or overwhelming you with theoretical physics or mathematical analysis of layouts. Emphasis is placed on the cross-sections of devices and carrier-based models of device operation as compared to the more common geometric and schematic representation of devices.

The 3rd Edition is entirely rewritten to reflect changes in the field, including a new chapter on layout and new content on failure mechanisms, resistors, capacitors and inductors, bipolar transistors and their applications, the MOS transistor and more.

Published by Pearson (June 22nd 2023) - Copyright © 2024

ISBN-13: 9780138059071

Subject: Electrical Engineering

Category: Analog Electronics

  1. Device Physics
  2. Semiconductor Fabrication
  3. Layout
  4. Representative Processes
  5. Failure Mechanisms
  6. Resistors
  7. Capacitors and Inductors
  8. Matching of Resistors and Capacitors
  9. Bipolar Transistors
  10. Applications of Bipolar Transistors
  11. Diodes
  12. Field-Effect Transistors
  13. Applications of MOS Transistors
  14. Special Topics
  15. Assembling the Die
