Proteins: Secondary Structure

Introduction to Protein Secondary Structure

The secondary structure of a protein refers to the specific geometric arrangement of amino acids that results from hydrogen bonding between atoms in the backbone of the peptide chain. This structure is crucial for the overall shape and function of proteins. The two most common types of secondary structures are the alpha helix and beta-pleated sheet. Additionally, the triple helix is important in structural proteins such as collagen.

Alpha Helix

The alpha helix is a spiral structure stabilized by hydrogen bonds. These bonds form between the oxygen atom of the carbonyl group and the hydrogen atom of the amide group in the backbone, specifically between every fourth amino acid. This regular pattern of hydrogen bonding gives the polypeptide chain a helical shape, resembling a spiral staircase.

Hydrogen bonds: Occur between backbone atoms, not side chains.
Structure: Right-handed coil; each turn contains about 3.6 amino acids.
Example: Many globular proteins contain alpha helices.

Ribbon model showing alpha helix and beta-pleated sheet regions in a protein

Beta-Pleated Sheet

The beta-pleated sheet consists of polypeptide chains arranged side by side, forming a sheet-like structure. Hydrogen bonds form between the carbonyl oxygen atoms and hydrogen atoms in the amide groups of adjacent chains, resulting in a pleated appearance.

Hydrogen bonds: Occur between different segments of the polypeptide chain or between different chains.
Structure: Sheet-like, with zigzag folds.
Example: Silk fibroin is rich in beta-pleated sheets.

Triple Helix

The triple helix is a secondary structure found in collagen and other structural proteins. Three polypeptide chains are woven together, and hydrogen bonds hold the chains together, providing strength and stability.

Structure: Three peptide chains twisted together like a rope.
Function: Provides structural support in connective tissue, skin, tendons, and cartilage.
Example: Collagen fibers are composed of triple helices.

Summary Table: Types of Protein Secondary Structure

Type	Structure	Hydrogen Bonding	Example
Alpha Helix	Spiral coil	Within same chain	Globular proteins
Beta-Pleated Sheet	Sheet-like, zigzag	Between chains or segments	Silk fibroin
Triple Helix	Three chains woven	Between chains	Collagen

Protein Structure Identification

Primary structure: Sequence of amino acids in a polypeptide chain.
Triple helix: Three peptide chains woven like a rope.
Alpha helix: Corkscrew shape with hydrogen bonds between amino acids.
Beta-pleated sheet: Polypeptide chains held side by side by hydrogen bonds.

Chemistry Link to Health: Protein Secondary Structures and Disease

Protein secondary structures are directly linked to health and disease. In Alzheimer’s disease, beta-amyloid proteins in the brain change from their normal alpha-helical form (soluble) to sticky beta-pleated sheets (insoluble), forming clusters called plaques. These plaques, along with neurofibrillary tangles, disrupt nerve signal transmission and are diagnostic markers of the disease.

Normal brain: Beta-amyloid proteins are alpha-helical and soluble.
Alzheimer’s brain: Beta-amyloid proteins form beta-pleated sheets, leading to insoluble plaques.
Diagnosis: Presence of plaques and tangles in neurons.

Key Terms and Definitions

Amino acid: Building block of proteins, containing an amine group, carboxylic acid group, and a side chain (R group).
Peptide bond: Covalent bond joining two amino acids.
Hydrogen bond: Weak interaction between a hydrogen atom and an electronegative atom (such as oxygen or nitrogen).
Alpha helix: Spiral secondary structure stabilized by hydrogen bonds.
Beta-pleated sheet: Sheet-like secondary structure stabilized by hydrogen bonds.
Triple helix: Three polypeptide chains woven together, found in collagen.

Relevant Equations

While secondary structure is not described by a specific equation, the formation of hydrogen bonds can be represented as:

This shows the hydrogen bond between the carbonyl oxygen and the amide hydrogen in the backbone.

Additional info:

Ribbon models and ball-and-stick models are commonly used to visualize protein secondary structures, highlighting regions of alpha helices and beta-pleated sheets.
Collagen’s triple helix structure is essential for the mechanical strength of connective tissues.
