28. Magnetic Fields and Forces

Magnetic Force on Current-Carrying Wire

# Magnetic Force on Current-Carrying Wire

Patrick Ford

1101

10

4

Was this helpful?

Bookmarked

Hey, guys. So in this figure, we're gonna talk about forces acting on current carrying wires, Meaning if you have a wire and charges moving through it, it has a current. And if that wire is inside of a magnetic field, it will feel a force. Let's check it out. All right. So remember, charges can move in space, and we've done this. If you have a little charge moving through space and it walks into a magnetic field, it will feel a magnetic force. Well, charges can also move inside of a wire. And if you have charges inside of a wire, you have a current. You can think of a wire as simply a, um ah, way to sort of restrict the path of charges that they're not going crazy directions. They have to move along the direction of the wire. But in a way, ah, wire is simply charges moving just the same. So remember, if charges air moving in space, they will be producing a new magnetic fields. And we did this. The equation is mu, not Q v sign of data over four pi R square, right, Just like how a charge moving freely through space will produce a new magnetic fields away from itself. A charge moving in a wire. In other words, if you have a current carrying wire that is also going to produce a new magnetic field, Okay, the equation for that is mu not I divided by two pi r so look somewhat similar to this, but it's not exactly the same. We're not gonna talk about this now. We're gonna talk about this later, but I want to make the point that they produce a charge. They produce the fields away. Um, the Y will produce the fields away from itself. Remember that charges not only produce a field away from themselves, but they're also going to feel a force if they are in the presence of an existing magnetic field. And this is a really important theme of magnetism is that moving charges produce a field, and if they are in an existing field, they will also feel a force. And just like how this happens for charges in space, this is also going to happen for charges moving in a wire. Okay, so if a charge is moving through space, it will feel a force given by Q V. The sign of data right s O. For example, if you have a magnetic field this way and a charge moving this way, you can use your right hand rule and figure out that the force will be the force will be into the field. Okay. Similarly, if a charge is moving, not through free space, but it's moving inside of a wire. It is a current, and that wire will will feel a force as well. So charge moving in an existing field, fields of force and the wire in an existing field also feels the force because it's the same thing just and here it has to be moving. And here it has to have a currents. It's a current carrying wire, right? Just like here, current carrying wire. And that force is going to be given by B I hell sign of theta. Okay, And this is the big equation that we're going to talk about. I wanted to sort of do a big summary of all the different situations, but this is what we're gonna talk about for the next few videos. Now, most textbooks and professors write this equation of different order. I like to write it this way just because there's so much crap to room. In this chapter, this spells bill, which is easier to remember than some other combination. Okay, so F equals built sign of data. I has a direction which is direction of the wire and B has a direction and data is that three angle between those two directions. The directions of the forces will be given always by the right hand rule. Now remember, there's sort of this exception that if you have a negative charge, if you have a negative charge that's moving freely, then you're going to use the left hand rule. But in currents because of sign convention, you are always going to use the right hand rules at the right hand rule. Every time When you have a current, you don't have a negative current right. Eso you're always going to use the right hand rule no matter what. Alright, eso The last thing we'll talk about here is that this force will cause the wire to bend slightly. Okay, so it causes the wire to bend slightly. So let's say here we have a wire here and the current is up And here we have a wire between these two magnets and the current is moving down. Now, you may remember that magnetic fields go from positive to negative on the outside. So positive to negative. So it looks like this. But more importantly, we want to know what is the fields around here? Well, it goes from positive. I'm sorry. From north to south, from north to south, so it's gonna look like this. So as far as the wires concern, you have Byfield lines going this way, I guess. This way. Okay. So what is the direction of the magnetic force that this wire will experience? Well, right hand rule, right? And guess what current is the direction of the motion. So it's gonna be your thumb, and your B is going to be your fingers. So here I have might be is gonna go to the right, and I want my current to go up. So this is already in the direction that I want, right? This matches the picture. So if I do this notice that my poem is away from me, right? So please do this. It's away from you. Which means that it's into the page. So this force on the force of the wire will be into the page everywhere the wires being pushed into the page. Okay, we can't calculate this because it's with magnets, but we're just talking about the direction here you also have north to south. So the magnetic field look the same. And what do you think will be the direction of the force? Well, hopefully you're thinking, Well, if we're flipping the current, it must flip the force. And that's correct. So, right hand rule again. This is going to the right. But now my currents down. So the only way that I can keep these going to the right with my current going down if I do this right, and if I do this on your sort of, bring it close to your face, right? This is weird. But hopefully see that your palm is facing you, which means it's coming out of the page. So FB is coming out of the page everywhere so F b is out of page. So that's direction of the force. Let's do, um, example. Here there are two parts, so it says here a 2 m long wire. That's the length of the wire l equals two is passed through. A constant magnetic field has shown. So there's a little piece of wire here, and you might be wondering, How is their current on a little piece of wire that's floating? Don't worry about that. For now. I'll talk about that a little bit later. Just assume that this is possible, which it is. Okay, so there's a wire there. Somehow it's connected to a battery, but don't worry about it. So the piece of the wire there is 2 m. It sits through a constant magnetic fields. This magnetic field is going into the page by and you can tell by the little excess. And we wanna know for part A. If the wire experiences a force of three Newton's when it has a current of four, what is the strength of the wire? What is the strength of the field? So what is be So is there an equation that ties these guys together so that you can find me? And it's the equation we talked about earlier. F equals Bill Bill, Sign of Fada. Okay, we're looking for be B equals FB divided by I l sign of data. Remember, the angle is the theta is the angle between the B and the I. I is either to the right or to the left. We actually don't know, but it's either one of those in the direction of the field is into the page. So the current is going this way or this way. Right this way, this way, and the field is going into the page so they make 90 degrees with each other. It's either this, which is 90 degrees right here, or it's this right, which is also 90 degrees. So this angle here is 90 degrees. And by the way, generally speaking, if you don't see like a weird angle, it's probably 90 right? Um, so let's plug these numbers. That f is three. I is four. L is, too. This is 3/8, and that is 0.3 75 Tesla. That's part a part B has to do with the direction. It's as if the wide experiences a downward force. So if the wide experience down force what most the direction of the current be, so here's the wire, and it's experiencing of force F B. That's down right hand rule the forces down. So I want my palm to be down. And, um, I want my four fingers for field to be going into the page, which into the page is away from you, right? So I want my fingers like this and I want this force down. Notice what happens with my thumb, which is It's going left and that's it. That tells me that the currents must be going left so the direction of the current is left. That's all there is to this. Hopefully makes sense. Let's keep going.
