18. Cardiovascular System: the Heart

Conduction system of the heart and the conduction pathway

Heart Physiology: Electrical Events

Electrical Conduction System of the Heart Cardiac

 AV node, subendocardial conducting network, AV node, AV bundle, right and left bundle branches

 Impulses generated by the SA node spread to the AV node, then to the AV bundle, then to the bundle branches, and finally to the subendocardial conducting network (Purkinje fibers).

 SA node, subendocardial conducting network, AV node, AV bundle, right and left bundle branches

 SA node, AV node, AV bundle, right and left bundle branches, subendocardial conducting network

 subendocardial conducting network, AV node, AV bundle, right and left bundle branches, SA node

 AV node, SA node, subendocardial conducting network, AV bundle, right and left bundle branches

 Choose the correct sequence of electrical current flow through the heart wall.

Intrinsic Conduction System of the Heart

 heart block: uncoordinated atrial and ventricular contraction

 Extrasystole, or premature contraction, can be caused by ectopic or abnormal pacemakers (also called ectopic foci). An ectopic focus can result when the sinoatrial (SA) node is defective. Additionally, some substances (such as caffeine and nicotine) consumed in excess can generate an ectopic focus. Any defect in the intrinsic conduction system of the heart can generate an irregular heart rhythm (an arrhythmia). Damage to the atrioventricular (AV) node can lead to a heart block. In a complete heart block, impulses do not reach the ventricles; as a result, the ventricles beat at their intrinsic rate, which is too slow to maintain adequate circulation. Fibrillation is characterized by rapid and irregular or out-of-phase contractions of the heart chambers.

 arrhythmia: atrioventricular (AV) node failure

 Which of the following are correctly paired?

 subendocardial conducting network (Purkinje fibers)

 The SA node generates impulses faster than the other node and sets the pace for the heart.

 The normal pacemaker of the heart is the __________.

Cardiac Muscle Action Potential Diagram

Heart: Excitation-Contraction Coupling

 Repolarization abnormalities are represented by a prolonged Q-T interval on an ECG. An enlarged ventricle would appear as an enlarged R wave on an ECG.

 A myocardial infarction would appear as elevation of the S-T segment on an ECG. An enlarged ventricle would appear as an enlarged R wave on an ECG.

 An elevated S-T segment on an ECG indicates cardiac ischemia. An enlarged ventricle would appear as an enlarged R wave on an ECG.

 An enlarged R wave on an ECG would indicate __________.

Cardiac Action Potential

EKG/ECG Interpretation

 Pacemakers are noncontractile cardiac muscle cells with an unstable resting membrane potential.

 The noncontractile cardiac muscle cells that initiate their own depolarization and cause depolarization of the rest of the heart are called __________.

 The P wave reflects the depolarization of the atria. The QRS complex shows ventricular depolarization, and the T wave is generated by ventricular repolarization. Since the QRS complex is so large, it obscures the wave that is generated by atrial repolarization.

 The P wave of an electrocardiogram represents __________.

 The vagus nerve carries parasympathetic fibers to the SA node.

 The __________ nerve carries parasympathetic fibers to the sinoatrial (SA) node.

IP Intrinsic Conduction System of the Heart

 An impulse of the heart originates at the sinoatrial (SA) node. The impulse is then transmitted to the atrioventricular (AV) node, where the impulse slows down to allow the atria to completely contract, thereby filling the adjacent ventricles. The AV node then transmits the impulse to the atrioventricular bundle (bundle of His), which branches into left and right bundle branches. The bundle branches give rise to the subendocardial conducting network (Purkinje fibers), which transmit the impulse to the ventricle walls and stimulate ventricular contraction.

 slow down impulses so that the atria can contract to fill the adjacent ventricles with blood

 conduct impulses to the sinoatrial node (SA node)

 The role of the atrioventricular node (AV node) is to __________.

 the muscle cell will not respond to a stimulus of any strength

 the muscle cell will respond only to an exceptionally strong stimulus

 During the absolute refractory period, a muscle cell will not respond to a stimulus of any strength.

 the muscle cell is ready to respond to any stimulus

 the muscle cell will respond only to a sub-threshold stimulus

 the muscle cell is ready to respond to a threshold stimulus

 The absolute refractory period refers to the time during which __________.

Action Potentials in Autorhythmic Cells

EKG - Abnormal Heart Rhythms

Cardiac Conduction System

Conducting System of the Heart

Cardiac Conduction System and Understanding ECG
