11. Bonding & Molecular Structure

Dipole Moment

1.5 Polarity

Consider the collection of nonmetallic elements: B, As, O,
and I. (a) Which two would form the most polar single
bond?

Dipole arrow is representative of bond polarity between 2 elements and points towards a more EN element.

Electronegativity increases moving from left to right and going up a group.

Arrange the bonds in each of the following sets in order
of increasing polarity: (c) C¬S, B¬F, N¬O.

The Chemical Bond: Covalent vs. Ionic and Polar vs. Nonpolar

Bond Polarity, Electronegativity and Dipole Moment - Chemistry Practice Problems

(b) If you were to put HBr under very
high pressure, so its bond length decreased significantly,
would its dipole moment increase, decrease, or stay the
same, if you assume that the effective charges on the atoms
do not change?

Polar Bonds, Polarity and Intermolecular Forces

Two dichloroethylene molecules with the same chemical formula
1C2H2Cl22, but different arrangements of atoms are shown.

(b) Which form of dichloroethylene has a dipole moment of 2.39 D, and which has a dipole moment of 0.00 D?

(b) It turns out that ozone, O3, has a small dipole moment. How is
this possible, given that all the atoms are the same?

Dipole Moment Example 2

Match the following descriptions with the type of bond (ionic, nonpolar covalent, covalent).
(a) One or more electrons are transferred from a metal to a nonmetal atom.

Which of the substances CdBr2, P4, BrF3, MgO, NF3, BaCl2, POCl3, and LiBr contain bonds that are:
(b) nonpolar covalent?

(b) What would you expect for the magnitude and direction of the bond
dipoles in this series?

Electronegativity: bond character/bond type: electronegativity difference and predicting bond type

(c) The measured dipole moment of BrCl is 0.57 D. If you assume the
bond length in BrCl is the sum of the atomic radii, what are
the partial charges on the atoms in BrCl using the experimental
dipole moment?

Differences in EN between bonds help us classify the different types of bonds possible.

Which of the substances S8, CaCl2, SOCl2, NaF, CBr4, BrCl, LiF, and AsH3 contain bonds that are:
(a) largely ionic?
(b) nonpolar covalent?
(c) polar covalent?

The substance chlorine monoxide, ClO(g), is important in
atmospheric processes that lead to depletion of the ozone
layer. The ClO molecule has an experimental dipole moment
of 1.24 D, and the Cl¬O bond length is 160 pm. (b) Based on the
electronegativities of the elements, which atom would you
expect to have a partial negative charge in the ClO molecule?

(b) Using these partial charges and the atomic radii given in Figure
7.8, estimate the dipole moment of the molecule.

Arrange the following molecules in order of decreasing dipole moment.H–I &nbsp; &nbsp; &nbsp; &nbsp; &nbsp; H–F &nbsp; &nbsp; &nbsp; &nbsp; H–Br &nbsp; &nbsp; &nbsp; &nbsp; H–Cl

Order the following compounds according to the increasing ionic character of their bonds: CCl4, BaCl2, TiCl3, ClO2.

(c) Does the molecule BF2Cl have a dipole moment?

The iodine monobromide molecule, IBr, has a bond length
of 249 pm and a dipole moment of 1.21 D. (a) Which atom of
the molecule is expected to have a negative charge?

Which of the following correctly identifies the chemical bond between a carbon and oxygen atom?a) Polar Covalentb) Pure Covalentc) Nonpolar&nbsp;d) Ionic

Arrange the bonds in each of the following sets in order
of increasing polarity: (b) O¬Cl, S¬Br, C¬P

Draw the Lewis structure for BrF with an arrow representing the
dipole moment.

Molecular polarity | AP Chemistry | Khan Academy

Ionic Bonds, Polar Covalent Bonds, and Nonpolar Covalent Bonds

Dipole Moment Example 1

Chemical Bonds: Ionic and Covalent

The O¬H bond lengths in the water molecule 1H2O2 are
96 pm, and the H¬O¬H angle is 104.5°. The dipole moment
of the water molecule is 1.85 D. (b) Calculate the magnitude of the bond dipole of the O¬H bonds. (Note: You will need to use vector addition
to do this.)

Polar Covalent Bonds and Nonpolar Covalent bonds, Ionic Bonding - Types of Chemical Bonds

Determine if a bond between each pair of atoms would be pure
covalent, polar covalent, or ionic.
a. Br and Br
b. C and Cl
c. C and S
d. Sr and O

(a) Does CS2 have a dipole moment? If so, in which direction
does the net dipole point?

Which of the following bonds are polar? (a) C¬O,
(b) Sl¬F, (c) N¬Cl, (d) C¬Cl. Which is the more electronegative
atom in each polar bond?

Show the direction of polarity for each of the bonds in Problem 7.51 using the  notation.
(b) Si-Li or Si-Cl

Which of the following substances contain bonds that are largely ionic?
(a) HF
(b) HI
(c) PdCl2
(d) BBr3
(e) NaOH
(f) CH3Li
